Siemens CPU 313C Hardware And Installation Guide

&RQILJXULQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
5-10 A5E00105492-03
([DPSOHRIDIXOODVVHPEO\
The figure shows the arrangement of modules in an S7-300 assembly on 4 racks.
IM
IM
CPU
PS
SM1
SM2
SM3
SM 4
SM5
SM6
SM7
SM8
PS
PS
4
3
2
1
5
4
5
5
6
SM1
SM2
SM3
SM 4
SM5
SM6
SM7
SM8
SM1
SM2
SM3
SM 4
SM5
SM6
SM7
SM8
SM1
SM2
SM3
SM 4
SM5
SM6
SM7
SM8
IM
IM
IM
IM
Figure 5-5 Full assembly using racks
7KHGLDJUDPLOOXVWUDWHVXQGHUQXPEHU
 Rack 0 (central unit)
 Rack 1 (expansion module)
 Rack 2 (expansion module)
 Rack 3 (expansion module)
 Connection cable 368
 Restriction for CPU 31xC: when this CPU is used, you must not insert Signal Module 8 on Rack 4.

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
