S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
11-25
0RGXOHGLDJQRVWLFV
Module diagnostics indicate the configured address area of intermediate memory
that has received an entry.
Byte 6
7 6 5 4 3 2 1 0 Bit No.
Length of the module diagnostics incl. byte 6
(dependent on the number of configured
address areas up to 6 byte)
Byte 7
Entry for 2nd configured address area
Entry for 3rd configured address area
Entry for 4th configured address area
Entry for 5th configured address area
Byte 8
Entry for 6th to 13th configured address area
0 1
Entry for 30th configured address area
Entry for 31st configured address area
Preset ≠ actual configuration
Code for module diagnostics
Entry for 1st configured address area
Entry for 14th to 21st configured address area
Byte 9
Byte 10
Entry for 22nd to 29th configured address area
Byte 11
Entry for 32nd configured address area
0 0 0 0 0
Preset ≠ actual configuration or Slave CPU in STOP
Preset ≠ actual configuration
7 6 5 4 3 2 1 0 Bit No.
7 6 5 4 3 2 1 0 Bit No.
7 6 5 4 3 2 1 0 Bit No.
7 6 5 4 3 2 1 0 Bit No.
7 6 5 4 3 2 1 0 Bit No.
Figure 11-7 Structure of the ID-specific diagnostics for CPU 31x-2

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
