S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
5-32 A5E00105492-03
 %DVLF3ULQFLSOHVRI03,'3DQG3W36XEQHWV
03,352),%86'33W3
These subnets are the most frequently used for S7-300 CPUs, so they are
discussed in detail below.
&RQYHQWLRQ'HYLFH 1RGH
In the following, all networked devices are referred to as nodes.
6HJPHQW
A segment is a bus link between two terminating resistors. A segment can include
up to 32 nodes. It is also limited by the permitted line length, depending on the
transmission rate.
7UDQVPLVVLRQUDWH
These maximum transmission rates are possible:
• MPI
– CPU 317-2 DP: 12 Mbps
– All other CPUs: 187.5 Kbps
• PROFIBUS DP: 12 Mbps
• PtP:
– Half duplex: 38.4 Kbps
– Full duplex: 19.2 Kbps
1XPEHURIQRGHV
Maximum possible number of nodes per subnet:
Table 5-13 Nodes on the subnet
3DUDPHWHUV 03, 352),%86'3 3W3
Number 127 126
1)
2
Addresses 0 to 126 0 to 125 -
Remarks Default: 32 addresses
Reserved are:
• address 0 for PG
• address 1 for OP
of those:
1 Master (reserved)
1 PG connection (address 0
reserved)
124 slaves or other masters
-
1)
Note the CPU-specific maximum specifications in the CPU manual.

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
