&RPPLVVLRQLQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
9-26 A5E00105492-03
6WDUWXSRIWKH'3PDVWHUV\VWHP
&38['3[&'3LVD'3PDVWHU
Customize the start-up monitoring time for DP slaves in parameter 0RQLWRULQJWLPHIRU
SDUDPHWHUWUDQVIHUWRPRGXOHV.
That is, the DP slaves must start up within the set time and be configured by the CPU (as
DP master).
352),%86DGGUHVVRIWKH'3PDVWHU
For the DP CPU, you must QRWset as a PROFIBUS address.
 &RPPLVVLRQLQJWKH&38DV'36ODYH
5HTXLUHPHQWVIRUFRPPLVVLRQLQJ
• The DP master is configured and programmed.
• If the MPI/DP interface of CPU 317-2 DP is to be operated as DP interface, you
must configure the interface accordingly.
• Prior to commissioning, you must assign and configure the DP CPU as a DP
slave. That is, in 67(3 you must:
– "switch on" the CPU as DP slave,
– assign a PROFIBUS address to the CPU,
– assign a slave diagnostic address to the CPU,
– specify whether the DP master is an S7 DP master or another DP master,
– specify the address areas for data exchange with the DP master.
• All other DP slaves are programmed and configured.
&URVVUHIHUHQFH
Information on changing over to a CPU 31xC, 312, 314, 315-2 DP, and 317-2DP
can be found in the applicable section in the&38'DWD[&DQG[Reference
Manual

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
