Siemens CPU 313C Hardware And Installation Guide

&RPPLVVLRQLQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
9-30 A5E00105492-03
6DPSOHSURJUDP
Below you will see a small sample program for data exchange between DP master
and DP slave. The addresses used in the example are found in the table above.
,QWKH'3VODYH&38 ,QWKH'3PDVWHU&38
L 2
T MB 6
L IB 0
//Data pre-
processing in
the
DP slave
T MB 7
L MW 6
T PQW 310
// Forward data
to the
DP master
L PIB 222
T MB 50
L PIB 223
// processing data
received
in the DP master
.
L B#16#3
+ I
T MB 51
L 10 //Data preparation in
DP master
+ 3
T MB 60
CALL SFC 15 //Send data to
DP slave
LADDR:= W#16#0
RECORD:= P#M60.0 Byte 20
RET_VAL:=MW 22
CALL SFC 14
LADDR:=W#16#D
//receive data
from DP master
RET_VAL:=MW 20
RECORD:=P#M30.0 byte 20
L MB 30
L MB 7
+ I
//Reprocess
received data
T MW 100


Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
