Siemens CPU 313C Hardware And Installation Guide


S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
11-1
7HVWLQJ)XQFWLRQV'LDJQRVWLFVDQG)DXOW(OLPLQDWLRQ

 ,QWKLV&KDSWHU
,QWURGXFWLRQ
This Chapter helps you to get acquainted with tools you can use to carry out the
following tasks:
• Hardware/software error diagnostics.
• Elimination of hardware/software errors.
• Testing the hardware/software - for example, during commissioning.
1RWH
It would go beyond the scope of this manual to provide detailed descriptions of all
the tools you can use for diagnostics, testing and troubleshooting functions.
Further notes are found in the relevant hardware/software manuals.
 2YHUYLHZ7HVWLQJ)XQFWLRQV
6RIWZDUHWHVWLQJIXQFWLRQV0RQLWRULQJDQGPRGLI\LQJRIYDULDEOHVVLQJOHVWHS
PRGH
STEP 7 offers you the following testing functions you can also use for diagnostics:
• Monitoring and modifying of variables
Can be used for PG/PC monitoring of specific CPU or user program variables.
You can also declare permanent values for the variables.
• Testing with program status
You can test your program by viewing the program status of each function
(result of logical links, status bit) or the data of specific registers in real-time
mode.
For example, if you have selected the programming language LAD in STEP 7
for your presentation, the color of the symbol will indicate a closed switch or an
active circuit.

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
