S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
12-16 A5E00105492-03
&DEOHVIRU DQGFDEOHVIRU 5XQ
• Bus signals, shielded
(PROFIBUS)
• Data signals, shielded
(programming devices,
operator panels, printers,
counter inputs, etc.)
• Analog signals, shielded
• DC voltage (≤ 60 V),
unshielded
• Process signals (≤ 25 V),
shielded
• AC voltage (≤ 25 V),
unshielded
• Monitors (coaxial cable)
In separate bundles or cable
ducts (no minimum clearance
necessary)
• DC voltage (> 60 V and
≤ 400 V), unshielded
• AC voltage (> 25 V and
≤ 400 V), unshielded
In common bundles or cable
ducts
• DC voltage (> 60 V and
≤ 400 V), unshielded
• AC voltage (> 25 V and
≤ 400 V), unshielded
• DC and AC voltage (> 400 V),
unshielded
LQVLGHFDELQHWV
In separate bundles or cable
ducts (no minimum clearance
necessary)
RXWVLGHFDELQHWV
On separate cable racks with a
clearance of at least 10 cm
• Bus signals, shielded
(PROFIBUS)
• Data signals, shielded
(programming devices,
operator panels, printers,
counter inputs, etc.)
• Analog signals, shielded
• DC voltage (≤ 60 V),
unshielded
• Process signals (≤ 25 V),
shielded
• AC voltage (≤ 25 V),
unshielded
• Monitors (coaxial cable)
LQVLGHFDELQHWV
In separate bundles or cable
ducts (no minimum clearance
necessary)
RXWVLGHFDELQHWV
On separate cable racks with a
clearance of at least 10 cm
DC and AC voltage (> 400 V),
unshielded
• DC and AC voltage (> 400 V),
unshielded
In common bundles or cable
ducts
ETHERNET In common bundles or cable
ducts
ETHERNET
Others In separate bundles or cable
ducts with a clearance of at least
50 cm

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
