,QVWDOODWLRQ2UGHU
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
3-2 A5E00105492-03
%DVLFUXOHVIRUWURXEOHIUHHRSHUDWLRQRI6
An S7 system can be used in many different ways, so we can only provide basic
rules for the electrical and mechanical installation in this section.
You must at least keep to these basic rules if you want your S7 system to operate
correctly.
0RGLI\LQJWKHVWUXFWXUHRIDQH[LVWLQJ6V\VWHP
If you want to modify the configuration of an existing system at a later time,
proceed using the steps indicated above.
1RWH
If you want to install a signal module at a later time, consult the relevant
information for the respective module.
&URVVUHIHUHQFH
Also note the description of your specific module in the 6,0$7,&63/&V
manual and the0RGXOH'DWD5HIHUHQFH0DQXDO.

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
