S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
6-7
 ,QVWDOOLQJ0RGXOHVRQWKH5DLO
5HTXLUHPHQWIRULQVWDOOLQJWKHPRGXOH
• Configuration of the automation system is complete.
• The rail is installed.
2UGHURIWKHPRGXOHV
Snap the modules onto the rail, starting at the left and in the following order:
1. Power supply module
2. CPU
3. signal modules, function modules, communication modules, interface modules
1RWH
If you install SM 331 analog input modules, please check EHIRUH installation
whether you have to reposition the measuring range submodules at the side of the
module. See Chapter 4 on analog modules in the 0RGXOH'DWD Reference Manual.
1RWH
If you want to create the S7-300 with a floating reference potential, you must
establish this state on the CPU, ideally before you attach it to the rail. The section
entitled &UHDWLQJDQ6ZLWKIORDWLQJUHIHUHQFHSRWHQWLDO contains the
necessary instructions.


Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
