4BMounting / Instal
lation
50BDetector
dust ca
p FDZ2
91
5
111
|
138
Building T
echnologies
007004_t_
en_
--
Fire Safety
2015
-
11
-
04
5.20
Detector
dust cap FD
Z291
During th
e constr
uction
phas
e the detect
or may b
e cov
ered w
ith a d
etector d
ust
cap FDZ29
1 to pr
otect it fr
om dust
and dir
t.
Mounting / removal of detector dust cap FDZ291
1
Detector
2
Detector dus
t cap
3
Remove the detector dust cap either manually by turning it to the right, or by using a detector
exchanger
and tester.
FDZ291
1
2
3
110
112
