Siemens FDOOT241-A3 User Manual

2BStructure and function
22BAccessories
3
46
| 138
Building Technologies
007004_t_en_--
Fire Safety
2015-11-04
3.7 Accessories
3.7.1 Addressable detector base FDB221/FDB221-AA
● For the mounting of point detectors and alarm sounders
● For the recess-mounted cable entry
● For surface-mounted cable entry, up to 6 mm cable
diameter
● Orange terminal block
● Detector base FDB221-AA additionally with a micro
terminal
● Compatible with:
● Order no. FDB221: A5Q00001664
● Order no. FDB221-AA: A5Q00012741
See also
 Collective and addressable detector base
FDB201/221 [➙ 74]
3.7.2 Collective detector base FDB201/FDB201-AA
● For the mounting of point detectors
● For the recess-mounted cable entry
● For surface-mounted cable entry, up to 6 mm cable
diameter
● Gray terminal block
● Detector base FDB201-AA additionally with a micro
terminal
● Compatible with:
● Order no. FDB201: A5Q00003814
● Order no. FDB201-AA: A5Q00012742
See also
 Collective and addressable detector base
FDB201/221 [➙ 74]
3.7.3 Addressable detector base, flat FDB222
● For the mounting of point detectors and alarm sounders
● For the recess-mounted cable entry
● Directly attached to the mounting surface
● Orange terminal block
● Compatible with:
● Order no.: S54319-F1-A1
See also
 Flat detector base FDB202/222 [➙ 74]
