Siemens FDOOT241-A3 User Manual

0BAbout this document
11BRevision history
1
12
| 138
Building Technologies
007004_t_en_--
Fire Safety
2015-11-04
Modification index
Edition date
Brief description
n 2012-07-01 Resistance values in 'Connecting FDOOT241-A3, FDOOT241-A4 to existing systems'
chapter added, date format changed in line with ISO 8601 specifications (format:
yyyy-mm-dd)
m 04.2012 Adaptations and editorial changes
Approvals updated
l 04.2011 Document fully revised
New revision history
New accessories: Base adapter FDB241/FDB299
New fire detectors: FDOOT241-A3, FDOOT241-A4, FDOOT241-A9
k 03.2009 Sensitivities for FDOOT241-x with High Suppression now 2.3 and 8 %/m
Accessories with order no.
Detector base FDB2x1-AA with 1 micro terminal
FDSB291 compatible with heat detector FDT2xx (from ES ≥43)
Connection diagrams for shielded cables
j 06.2008 Safety instructions revised
Technical data restructured
i 02.2008 Chap. 4.3.1.3: Only parameter set 8 does not comply with standards EN 54-7 and
CEA 4021.
Parameter set 0 added to chaps. 4.3.2 and 4.3.3
Index added
h 02.2008 FM approvals added
IP protection category for FDB291/FDB293 corrected
Structure in 'Detector lines' chapter uniform
Various corrections to parameter sets of FDOOT241-x, FDO241, and FDT241
KMK in chap. 8.1.4: Parameter sets specified more precisely
New chapters: 'Default settings' and 'Protective cages'
New accessories:
- Detector base FDB202/FDB222
- Dummy detector FDX291
g 10.2007 Cross-reference list of detector names added to 'Overview' chapter
Display texts for detector exchanger and tester added in 'Diagnosis levels' chapter.
Various corrections to FDOOT241-x parameter sets
EMC-protective cage FDBZ294 included in accessories
'Mode' replaced by 'sensor mode'.
Additions in the 'Technical data'
- Line separator
- IP protection categories
- LPCB approvals
- Standard EN 54-17
Images with language texts replaced by language-neutral images
f 09.2006 Complete revision (devices with ES ≥30 included)
e 04.2005 Chapters 5.1, 5.3, 5.5.3, 5.7.2, 5.8.1, 5.8.2, 6.11.1, 6.11.2, 9.3.2, 9.3.3, 9.4, 9.5
d 01.2005 Chapters 4.4.1, 5, 9.3.1, 9.3.4, 9.3.6 and 9.4 adapted
c 12.2004 Text in chapter 0, titles 5.5.1, 5.5.2, 5.5.3 adapted
b 11.2004 Document layout adapted, parameter sets adapted, various minor changes
a 06.2004 First edition
