Mounting
The kit is installed by hand
1. Fold the sealing lip back.
2. Insert the detector base into the sealing element. Make sure that the opening in
the detector base lines up with the marking and opening on the rubber base.
Risk when piercing the rubber base with a tool!
Consequences: Leaks in rubber base
● Do not use tools for piercing!
3. Push the connection wires through the rubber base from the rear.
4. Install the detector base.
5. Place a point detector or alarm sounder in the detector base.
6. Turn the point detector or alarm sounder to the right to screw it firmly into the
detector base.
7. Screw the supplied set screw into the point detector or alarm sounder until it no
longer protrudes. This step is not needed when using detector locking device
FDBZ293.
8. Fold the folded-back sealing lip over the point detector or alarm sounder.
The sealing element is installed.
