Alphabetical Reference
82
LDAP Template File Name
• Only configurable on optiPoint 410/420 standard/advance and only
required if a display
module or application module is used.
•If an  LDAP server is used, enter the name of the LDAP template file
that is used in connection with this server.
• The file must exist in a defined directory on the  FTP server ( FTP
Server Address).
• Default name  Page 109.
• Download file  Action on Submit
 Page 60
LED Test
• Conduct this test to check the function of the  LED on the
optiPoint 410/420.
• All the LEDs blink during the test.
 Page 32
Line Status
• Activate the display to view the functions and values used to run the
 LAN connections on the optiPoint 410/420.
• Bit rate, activity, half / full duplex, as well as the status of the used
network or the manual setting on the optiPoint
410/420.
• The status is displayed by the  LEDs in the right-hand row:
• The status monitor remains active even during normal operation of the
optiPoint
410/420. However, it does not affect the operation of the
function keys.
 Page 35
Port
[1]
[1] See  Page 13.
Function LEDs on optiPoint 410/420
(right-hand row)
PC Activity LED1 Not Active Active
Speed LED2 10 Mbit/s 100 Mbit/s
Duplex LED3 Half-Duplex Full-Duplex
(no function) LED4 - -
LAN Activity LED5 Not Active Active
Speed LED6 10 Mbit/s 100 Mbit/s
Duplex LED7 Half-Duplex Full-Duplex
(no function) LED8 - -
