Alphabetical Reference
86
QCU Home Address
• Enter the  IP Address of the QCU server on which the QoS data is
logged.
• Default value  Page 109.
 Page 64
QDC Server
• Enter the  Port number for communication with the QDC server.
• Default value  Page 109.
 Page 66
QoS L2/L3
• The settings relate to the  Layer 2 and  Layer 3 areas of the
 QoS, which regulate the prioritization of the transferred data.
• For Layer 2, the  L2/L3 Voice/Signaling and the  L2 Default can be
changed. For Layer 3, the  L2/L3 Voice/Signaling can be changed.
• The activation of Layer 2 and / or Layer 3 support is meaningful only if
the
 Switch used can interpret this information (e.g. "Layer 2
Switch").
• Default value  Page 109.
 Page 24  Page 63
RAM Test
• You can test the  RAM memory of your optiPoint 410/420.
• The results are displayed after the test is over.
 Page 33  Page 59
Report Interval
• Time interval (in sec.) in which reports are sent.
• A QoS report is sent for each report interval if the  Report Mode was
set accordingly.
• Valid values: 10 ... 3600.
• Default value  Page 109.
 Page 64
Report Mode
• Choose the relevant report mode:
– 1: A report will be sent at the end of a session and only if the
threshold has been reached.
– 2: A report will be sent within each  Report Interval if the threshold
has been reached.
– 3: A report will always be sent at the end of a session.
– 4: A report will always be sent within each  Report Interval.
 Page 64
