Building Technologies Basic Documentation LME7... CC1P7105enr
3 Type summary 17.04.2018
3 Type summary
3.1 Burner controls
Parameterized burner control for the supervision of multistage or modulating oil/gas
forced draft burners and atmospheric burners of medium to higher capacity, in
intermittent operation. With controlled air damper control.
Article no.
BPZ:LME71.000A1 BPZ:LME71.000A2 BPZ:LME72.000A2 BPZ:LME73.000A1 BPZ:LME73.000A2
Type
LME71.000A1 LME71.000A2 LME72.000A2 *) LME73.000A1 LME73.000A2
Mains voltage AC 120 V
●
--- ---
●
---
Mains voltage AC 230 V ---
● ●
---
●
Gas pressure switch-min / POC
● ● ● ● ●
Pressure switch valve proving
● ● ● ● ●
Air pressure switch
● ● ● ● ●
Ionization probe
● ● ● ● ●
QRA2 / QRA4 / QRA10
● ● ● ● ●
Load controller analog input signal (0...10 V, 4...20 mA, 0...135 ς)
● ●
---
● ●
Load controller input 3-position step input / 2-stage
● ● ● ● ●
Output actuator control --- ---
● ● ●
Input feedback for actuator with potentiometer 0...1 kς --- --- ---
● ●
Output PWM control
● ● ● ● ●
Onboard LED 7-segment display
● ●
---
● ●
BCI bus for AZL2
● ● ● ● ●
*) On request
