Building Technologies Basic Documentation LME7... CC1P7105enr
3 Type summary 17.04.2018
3.3 External display and operating units
AZL21.00x9
Article no.: BPZ:AZL21.00x9
Display and operating unit, detached, choice of mounting
methods, 8-digit LCD, 5 buttons, BCI for LME7, degree of
protection IP40.
See Data Sheet N7542
AZL23.00x9
Article no.: BPZ:AZL21.00x9
Display and operating unit, detached, choice of mounting
methods, 8-digit LCD, 5 buttons, BCI for LME7, degree of
protection IP54.
See Data Sheet N7542
Built-in in the LME7
3-colored LED, reset button, 3 other buttons for operation in
connection with 3 x 7-segment display
AGV50.100
Article no.: BPZ:AZL21.00x9
Signal cable for AZL2, with RJ11 connector,
cable length 1 m, pack of 10
3.4 Flame detectors
QRA2
UV flame detector for the supervision of gas flames, yellow- /
blue-burning oil flames and for ignition spark proving.
Plastic insulated housing, metalized to prevent static charging
caused by the air flow from the fan, lateral illumination.
See Data Sheet N7712
QRA4
UV flame detector for the supervision of gas flames, yellow- /
blue-burning oil flames and for ignition spark proving, metal
housing, front illumination.
See Data Sheet N7711
QRA10
UV flame detector for the supervision of gas flames, yellow-
/ blue-burning oil flames and for ignition spark proving.
Die-cast aluminum housing with a 1 in. mounting coupling
and connection facility for cooling air.
See Data Sheet N7712
Ionization probe
Flame detector for Siemens burner controls, for supervision of
gas flames.
To be provided on site
