25/106
Building Technologies Basic Documentation LME7... CC1P7105enr
4 Technical data 17.04.2018
4 Technical data
4.1 Basic unit LME7
Mains voltage AC 120 V AC 230 V
Mains frequency 50/60 Hz 50/60 Hz
External primary fuse Max. 6.3 A (slow) Max. 6.3 A (slow)
Power consumption <10 W, typical <10 W, typical
Safety class
I with parts according to II and III to DIN
EN 60730-1
Degree of protection IP00
Β
Note:
The burner or boiler
manufacturer must ensure
degree of protection IP40 for
burner controls as per
DIN EN 60529 through
adequate installation of the
LME7
Rated surge voltage
category III (DIN EN 60664)
∂ LME7 total unit 4 kV
∂ Creepage distances or air gaps 2.5 kV due to voltage limitation
measures
Degree of contamination 2 in accordance with DIN EN 60730-1
Software class Class C in accordance with DIN EN
60730-2-5:2011
2-channel structure
Reaction time in the event of loss of
flame
Max. 1 s
Perm. mounting position Optional
Weight Approx. 490 g
