4.3 Terminal rating Outputs
Total contact loading:
∂ Rated voltage AC 120 V
50/60 Hz
AC 230 V
50/60 Hz
∂ Unit input current terminal X3-04
(safety loop) from:
- Fan motor contactor
- Ignition transformer
- Fuel valves
Max. 5 A Max. 5 A
Individual contact loading:
Fan motor X2-01 pin 3
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Rated current 2 A
(15 A max. 0.5 s)
2 A
(15 A for max. 0.5
s)
∂ Power factor Cosι ″0.4 Cosι ″0.4
Alarm output X2-03 pin 3
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Rated current 1 A 1 A
∂ Power factor Cosι ″0.6 Cosι ″0.6
Ignition transformer X4-02 pin 3
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Rated current 2 A 2 A
∂ Power factor Cosι ″0.4 Cosι ″0.4
Output relay contact K2/2 terminal X2-09 pin 7 (auxiliary output)
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Rated current 1 A 1 A
∂ Power factor Cosι ″0.4 Cosι ″0.4
Fuel valves / pilot valve X7-01 pin 3
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Rated current 1 A 1 A
∂ Power factor Cosι ″0.4 Cosι ″0.4
Fuel valves 1 X7-04 pin 4 / fuel valve 2 X7-02 pin 3
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Rated current
- Valve proving inactive
2 A 2 A
- Valve proving active 1 A 1 A
∂ Power factor Cosι ″0.4 Cosι ″0.4
Β
Note:
When activating valve proving (e.g. on shutdown), the load on the valve
terminals is restricted. If the load is not reduced, the design lifetime is about
100,000 burner start cycles!
Safety loop X3-04 pin 2, safety valve X6-03 pin 3, POC or connection PWM motor
X2-02 pin 3
∂ Rated voltage AC 120 V 50/60 Hz AC 230 V 50/60 Hz
∂ Total current 2 A 2 A
∂ Power factor Cosι ″0.4 Cosι ″0.4
Caution!
Maximum permissible current load may be exceeded!
If terminal X2-02 pin 3 is used as the connection for supplying the PWM
motor, no other motor may be connected on terminal X2-01 pin 3.
