4.1.2 LED States Inside the Electronics Cabinet
4.1.2.1 Base3DPM Status Indicator LEDs
Normal
Fault
Warning
Power Active
Heater 2
Temp Limit
Overtemp
Flameout
Ignite
Alternate Range
Power Active
Heater 1
Temp Limit
Overtemp
Figure 4-1 Base3DPM Status LEDs
General Maintenance and Troubleshooting
4.1 Analyzer Status Indicators
Maxum edition II Analyzer General Maintenance
Manual, August 2018, A5E42019842001 21
