4.6 Alarm Codes, Descriptions, and Suggested Actions
4.6.1 Alarms 301 - 324
GCP Alarm Descriptions 301 - 324
The following tables list the alarm number (#), type (+ information, ? warning, ! error) alarm
text, description, and actions.
# Text Description Action
301 ? External Message: send
failure %3
A message was received by the device
from itself; or source of message can't be
identified; or Gateway is too busy or com‐
munication was disrupted between the
GC and the message handler.
Reset Gateway or SYSCON.
302 ? External Message: server
lost
System Error Contact Customer Support.
303 + External Message: Rec'd
invalid communication
from unit %3
Message was received from Advance
DataHiway unit that had previously
broadcast with no slots or slot is out of
range.
Reset Advance DataHiway unit.
304 + External Message: Orphan
message received from %3
An Advance DataHiway external
PANDSP message was received with no
matching PANKEY; or an ATTACH was
received with no matching RATCH; or an
internal timeout was generated for non-
existent message.
Ignore or reset SYSCON.
305 ? External Message: Invalid
Message Length for %3
Advance DataHiway Results, print, HAE,
or Service Panel messages received
from GC that have no length.
Check database set up for these mes‐
sages.
306 + External Message: Send in‐
valid communication to unit
%3
Message from GC is directed to an Ad‐
vance DataHiway unit that has no slots,
an invalid range of slots, or no UID has
ever been received.
Check Advance DataHiway unit.
307 ? External Message: Dupli‐
cate anlz_id %3 detected ;
setting to zero
An Advance DataHiway ZIP message
was received from another Advance Da‐
taHiway unit, or another GC has broad‐
cast with the same analyzer num‐
ber.Check other units on network.
Check other units on network.
308 ? External Message: Dupli‐
cate UNIT %3 detected;
setting loop/unit to zero
An Advance DataHiway SLEEP mes‐
sage has been received. Another Ad‐
vance DataHiway unit has broadcast
with the same loop/unit.
Check other units on Advance DataHi‐
way and correct loop/unit of GC.
309 ? External Message:
RUD:Unit does not re‐
spond; loop/unit %3
Occurs when Advance DataHiway loop/
unit does not respond to a RUD message
- originates from I/O, Host, or Printer ta‐
ble in GC.
Remove extraneous references to non-
existent units. Check Advance Data‐
Hiway connection.
General Maintenance and Troubleshooting
4.6 Alarm Codes, Descriptions, and Suggested Actions
Maxum edition II Analyzer General Maintenance
Manual, August 2018, A5E42019842001 31
