4.6.22 Alarms 10000 - 11536 MicroSAM
GCP Alarm Descriptions - 10000 - 11536 MicroSAM
The following tables list the alarm number (#), type (+ information, ? warning, ! error) alarm
text, description, and actions.
# Text Description Action
10000 ! Temperature control failure
on %4
MicroSAM alarm Contact MicroSAM Support.
10001 ! Temperature sensor (RTD)
of %4 defective
MicroSAM alarm Contact MicroSAM Support.
10002 ! Temperature deviation on
%4 exceeds limits
MicroSAM alarm Contact MicroSAM Support.
10003 ! Temperature controller %4
disabled
MicroSAM alarm Contact MicroSAM Support.
10004 ! Carrier gas pressure low
on %4
MicroSAM alarm Contact MicroSAM Support.
10256 ! Detector %4 disabled MicroSAM alarm Contact MicroSAM Support.
10257 ! Detector %4 shorted MicroSAM alarm Contact MicroSAM Support.
10258 ! Detector %4 not connected MicroSAM alarm Contact MicroSAM Support.
10259 ! Carrier gas pressure low
on %4
MicroSAM alarm Contact MicroSAM Support.
10512 ! Pressure controller %4 dis‐
abled
MicroSAM alarm Contact MicroSAM Support.
10513 ! A/D converter failure on %4 MicroSAM alarm Contact MicroSAM Support.
10514 ? Operating pressure low on
%4
MicroSAM alarm Contact MicroSAM Support.
10515 ! Pressure exceeds limits on
%4
MicroSAM alarm Contact MicroSAM Support.
10516 ! Setpoint exceeds limits on
%4
MicroSAM alarm Contact MicroSAM Support.
10517 ! Pressure out of control on
%4
MicroSAM alarm Contact MicroSAM Support.
10518 ! Voltage exceeds limits on
%4
MicroSAM alarm Contact MicroSAM Support.
10519 ! Operating pressure low MicroSAM alarm Contact MicroSAM Support.
10768
-
10775
! Valve [1 – 8] operation fail‐
ure on %4
MicroSAM alarm Contact MicroSAM Support.
11536 ! General RSP communica‐
tion error on %4
MicroSAM alarm Contact MicroSAM Support.
General Maintenance and Troubleshooting
4.6 Alarm Codes, Descriptions, and Suggested Actions
Maxum edition II Analyzer General Maintenance
Manual, August 2018, A5E42019842001 81
