International English 5 System Parameters
MICROMASTER 440 Operating instructions
6SE6400-5CA00-0BP0
55
Par. No. Parametername Default Acc WS QC
P1800 Pulse frequency 4 2 CUT N
r1801 CO: Act. switching frequency - 3 - -
P1802 Modulator mode 0 3 CUT N
P1820[3] Reverse output phase sequence 0 2 CT N
P1911 No. of phase to be identified 3 2 CT N
r1925 Identified on-state voltage - 2 - -
r1926 Ident. gating unit dead time - 2 - -
Motor Data (P0004 = 3)
Par. No. Parametername Default Acc WS QC
r0035[3] CO: Act. motor temperature - 2 - -
P0300[3] Select motor type 1 2 C Q
P0304[3] Rated motor voltage 230 1 C Q
P0305[3] Rated motor current 3.25 1 C Q
P0307[3] Rated motor power 0.75 1 C Q
P0308[3] Rated motor cosPhi 0.000 2 C Q
P0309[3] Rated motor efficiency 0.0 2 C Q
P0310[3] Rated motor frequency 50.00 1 C Q
P0311[3] Rated motor speed 0 1 C Q
r0313[3] Motor pole pairs - 3 - -
P0320[3] Motor magnetizing current 0.0 3 CT Q
r0330[3] Rated motor slip - 3 - -
r0331[3] Rated magnetization current - 3 - -
r0332[3] Rated power factor - 3 - -
r0333[3] Rated motor torque - 3 - -
P0335[3] Motor cooling 0 2 CT Q
P0340[3] Calculation of motor parameters 0 2 CT N
P0341[3] Motor inertia [kg*m^2] 0.00180 3 CUT N
P0342[3] Inertia ratio total/motor 1.000 3 CUT N
P0344[3] Motor weight 9.4 3 CUT N
r0345[3] Motor start-up time - 3 - -
P0346[3] Magnetization time 1.000 3 CUT N
P0347[3] Demagnetization time 1.000 3 CUT N
P0350[3] Stator resistance (line-to-line) 4.0 2 CUT N
P0352[3] Cable resistance 0.0 3 CUT N
r0384[3] Rotor time constant - 3 - -
r0395 CO: Total stator resistance [%] - 3 - -
r0396 CO: Act. rotor resistance - 3 - -
P0601[3] Motor temperature sensor 0 2 CUT N
P0604[3] Threshold motor temperature 130.0 2 CUT N
P0610[3] Motor I2t temperature reaction 2 3 CT N
P0625[3] Ambient motor temperature 20.0 3 CUT N
P0640[3] Motor overload factor [%] 150.0 2 CUT Q
P1910 Select motor data identification 0 2 CT Q
r1912[3] Identified stator resistance - 2 - -
