5 System Parameters International English
MICROMASTER 440 Operating instructions
56 6SE6400-5CA00-0BP0
r1913[3] Identified rotor time constant - 2 - -
r1914[3] Ident. total leakage inductance - 2 - -
r1915[3] Ident. nom. stator inductance - 2 - -
r1916[3] Identified stator inductance 1 - 2 - -
r1917[3] Identified stator inductance 2 - 2 - -
r1918[3] Identified stator inductance 3 - 2 - -
r1919[3] Identified stator inductance 4 - 2 - -
r1920[3] Identified dyn.leak.induct. - 2 - -
Commands and Digital I/O (P0004 = 7)
Par. No. Parametername Default Acc WS QC
r0002 Drive state - 2 - -
r0019 CO/BO: BOP control word - 3 - -
r0050 CO: Active command data set - 2 - -
r0051[2] CO: Active drive data set - 2 - -
r0052 CO/BO: Act. status word 1 - 2 - -
r0053 CO/BO: Act. status word 2 - 2 - -
r0054 CO/BO: Act. control word 1 - 3 - -
r0055 CO/BO: Add. act. control word - 3 - -
P0700[3] Selection of command source 2 1 CT Q
P0701[3] Function of digital input 1 1 2 CT N
P0702[3] Function of digital input 2 12 2 CT N
P0703[3] Function of digital input 3 9 2 CT N
P0704[3] Function of digital input 4 15 2 CT N
P0705[3] Function of digital input 5 15 2 CT N
P0706[3] Function of digital input 6 15 2 CT N
P0707[3] Function of digital input 7 0 2 CT N
P0708[3] Function of digital input 8 0 2 CT N
P0719[3] Selection of cmd. & freq. setp. 0 3 CT N
r0720 Number of digital inputs - 3 - -
r0722 CO/BO: Binary input values - 2 - -
P0724 Debounce time for digital inputs 3 3 CT N
P0725 PNP / NPN digital inputs 1 3 CT N
r0730 Number of digital outputs - 3 - -
P0731[3] BI: Function of digital output 1 52:3 2 CUT N
P0732[3] BI: Function of digital output 2 52:7 2 CUT N
P0733[3] BI: Function of digital output 3 0:0 2 CUT N
r0747 CO/BO: State of digital outputs - 3 - -
P0748 Invert digital outputs 0 3 CUT N
P0800[3] BI: Download parameter set 0 0:0 3 CT N
P0801[3] BI: Download parameter set 1 0:0 3 CT N
P0809[3] Copy Command Data Set 0 2 CT N
P0810 BI: CDS bit 0 (Local / Remote) 0:0 2 CUT N
P0811 BI: CDS bit 1 0:0 2 CUT N
P0819[3] Copy Drive Data Set 0 2 CT N
P0820[3] BI: DDS bit 0 0:0 3 CT N
