Siemens MICROMASTER 440 Series User Manual

International English 5 System Parameters
MICROMASTER 440 Operating instructions
6SE6400-5CA00-0BP0
57
Par. No. Parametername Default Acc WS QC
P0821[3] BI: DDS bit 1 0:0 3 CT N
P0840[3] BI: ON/OFF1 722:0 3 CT N
P0842[3] BI: ON/OFF1 reverse 0:0 3 CT N
P0844[3] BI: 1. OFF2 1:0 3 CT N
P0845[3] BI: 2. OFF2 19:1 3 CT N
P0848[3] BI: 1. OFF3 1:0 3 CT N
P0849[3] BI: 2. OFF3 1:0 3 CT N
P0852[3] BI: Pulse enable 1:0 3 CT N
P1020[3] BI: Fixed freq. selection Bit 0 0:0 3 CT N
P1021[3] BI: Fixed freq. selection Bit 1 0:0 3 CT N
P1022[3] BI: Fixed freq. selection Bit 2 0:0 3 CT N
P1023[3] BI: Fixed freq. selection Bit 3 722:3 3 CT N
P1026[3] BI: Fixed freq. selection Bit 4 722:4 3 CT N
P1028[3] BI: Fixed freq. selection Bit 5 722:5 3 CT N
P1035[3] BI: Enable MOP (UP-command) 19:13 3 CT N
P1036[3] BI: Enable MOP (DOWN-command) 19:14 3 CT N
P1055[3] BI: Enable JOG right 0:0 3 CT N
P1056[3] BI: Enable JOG left 0:0 3 CT N
P1074[3] BI: Disable additional setpoint 0:0 3 CUT N
P1110[3] BI: Inhibit neg. freq. setpoint 0:0 3 CT N
P1113[3] BI: Reverse 722:1 3 CT N
P1124[3] BI: Enable JOG ramp times 0:0 3 CT N
P1230[3] BI: Enable DC braking 0:0 3 CUT N
P2103[3] BI: 1. Faults acknowledgement 722:2 3 CT N
P2104[3] BI: 2. Faults acknowledgement 0:0 3 CT N
P2106[3] BI: External fault 1:0 3 CT N
P2220[3] BI: Fixed PID setp. select Bit 0 0:0 3 CT N
P2221[3] BI: Fixed PID setp. select Bit 1 0:0 3 CT N
P2222[3] BI: Fixed PID setp. select Bit 2 0:0 3 CT N
P2223[3] BI: Fixed PID setp. select Bit 3 722:3 3 CT N
P2226[3] BI: Fixed PID setp. select Bit 4 722:4 3 CT N
P2228[3] BI: Fixed PID setp. select Bit 5 722:5 3 CT N
P2235[3] BI: Enable PID-MOP (UP-cmd) 19:13 3 CT N
P2236[3] BI: Enable PID-MOP (DOWN-cmd) 19:14 3 CT N
http://nicontrols.com

Siemens MICROMASTER 440 Series Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Control Modes	Vector control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
