International English 6 Troubleshooting
MICROMASTER 440 Operating instructions
6SE6400-5CA00-0BP0
71
Fault Possible Causes Diagnose & Remedy Reac-
tion
F0022
Powerstack fault
Fault caused by the following events:
(1) dc-link overcurrent = short circuit of
IGBT
(2) short circuit of chopper
(3) earth fault
Framesizes A to C (1),(2),(3)
Framesizes D to E (1),(2)
Framesize F (2)
Since all these faults are assigned to one
signal on the power stack, it is not
possible to establish which one actually
occurred.
Off2
F0030
Fan has failed
Fan no longer working Fault cannot be masked while options module (AOP
or BOP) is connected.Need a new fan.
Off2
F0040
Automatic
Calibration Failure
MM 440 only Off2
F0041
Motor Data
Identification
Failure
Motor data identification failed.
Alarm value =0: Load missing
Alarm value =1: Current limit level
reached during identification.
Alarm value =2: Identified stator
resistance less than 0.1% or greater than
100%.
Alarm value =3: Identified rotorresistance
less than 0.1% or greater than 100%.
Alarm value =4: Identified stator
reactance less than 50% and greater than
500%
Alarm value =5: Identified main reactance
less than 50% and greater than 500%
Alarm value =6: Identified rotor time
constant less than 10ms or greater than
5s
Alarm value =7: Identified total leakage
reactance less than 5% and greater than
50%
Alarm value =8: Identified stator leakage
reactance less than 25% and greater than
250%
Alarm value =9: Identified rotor leakage
inductance less than 25% and greater
than 250%
Alarm value = 20: Identified IGBT on-
voltage less than 0.5 or greater than 10V
Alarm value = 30: Current controller at
voltage limit
Alarm value = 40: Inconsistence of
identified data set, at least one
identification failed
Percentage values based on the
impedance Zb = Vmot,nom / sqrt(3) /
Imot,nom
0: Check that the motor is connected to the inverter.
1-40: Check if motor data in P304-311 are correct.
Check what type of motor wiring is required (star,
delta).
Off2
F0051
Parameter
EEPROM Fault
Read or write failure while saving non-
volatile parameter.
Factory Reset and new parameterization
Change drive
Off2
F0052
power stack Fault
Read failure for power stack information
or invalid data.
Change drive Off2
F0053
IO Eeprom Fault
Read failure for IO EEPROM information
or invalid data.
Check data
Change IO module
Off2
F0060
Asic Timeout
Internal communications failure If fault persists, change inverter
Contact Service Department
Off2
