Siemens MICROMASTER 440 Series User Manual

7 MICROMASTER 440 Specifications International English
MICROMASTER 440 Operating instructions
84 6SE6400-5CA00-0BP0
Input voltage range 3 AC 380 V – 480 V, ± 10 % (with built in Class A Filter), Part 2
Order No. 6SE6440- 2AD32-
2DA0
2AD33-
0EA0
2AD33-
7EA0
2AD34-
5FA0
2AD35-
5FA0
2AD37-
5FAO
[kW]
22.0 30.0 37.0 45.0 55.0 75.0
Motor Output Rating
[hp]
30.0 40.0 50.0 60.0 75.0 100.0
Output [kVA]
34.3 47.3 57.2 68.6 83.8 110.5
CT Output Cur. Max. [A]
45.0 62.0 75.0 90.0 110.0 145.0
CT Input Current [A]
43.1 58.7 71.2 85.6 103.6 138.5
VT Input Current [A]
59.3 71.7 86.6 103.6 138.5 168.5
VT Output Cur. Max. [A]
62.0 75.0 90.0 110.0 145.0 178.0
80 100 125 160 160 200
Recommended Fuse [A]
3NA3024 3NA3030 3NA3032 3NA3036 3NA3036 3NA3140
[mm
2
]
16.0 25.0 25.0 35.0 70.0 70.0
Input Cable Min.
[awg]
5332-2-2
[mm
2
]
35.0 35.0 35.0 150.0 150.0 150.0
Input Cable Max.
[awg]
2 2 2 -5 -5 -5
[mm
2
]
16.0 25.0 25.0 50.0 70.0 95.0
Output Cable Min.
[awg]
5330-2-3
[mm
2
]
35.0 35.0 35.0 150.0 150.0 150.0
Output Cable Max.
[awg]
2 2 2 -5 -5 -5
[kg]
17.0 22.0 22.0 75.0 75.0 75.0
Weight
[lbs]
37.0 48.0 48.0 165.0 165.0 165.0
w [mm]
275.0 275.0 275.0 350.0 350.0 350.0
h [mm]
520.0 650.0 650.0 1150.0 1150.0 1150.0
d [mm]
245.0 245.0 245.0 320.0 320.0 320.0
w [inches]
10.83 10.83 10.83 13.78 13.78 13.78
h [inches]
20.47 25.59 25.59 45.28 45.28 45.28
Dimensions
d [inches]
9.65 9.65 9.65 12.6 12.6 12.6
http://nicontrols.com

Siemens MICROMASTER 440 Series Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Control Modes	Vector control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
