Siemens MICROMASTER 440 Series User Manual

International English 7 MICROMASTER 440 Specifications
MICROMASTER 440 Operating instructions
6SE6400-5CA00-0BP0
85
Input voltage range 3 AC 380 V – 480 V, ± 10 % (Unfiltered), Part 1
Order No. 6SE6440-
2UD13-
7AA0
2UD15-
5AA0
2UD17-
5AA0
2UD21-
1AA0
2UD21-
5AA0
2UD22-
2BA0
2UD23-
0BA0
2UD24-
0BA0
2UD25-
5CA0
2UD27-
5CA0
[kW]
0.37 0.55 0.75 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Motor Output Rating
[hp]
0.5 0.75 1.0 1.5 2.0 3.0 4.0 5.0 7.5 10.0
Output [kVA]
0.9 1.2 1.6 2.3 3.0 4.5 5.9 7.8 10.1 14.0
CT Output Cur. Max. [A]
1.2 1.6 2.1 3.0 4.0 5.9 7.7 10.2 13.2 18.4
CT Input Current [A]
1.1 1.4 1.9 2.8 3.9 5.0 6.7 8.5 11.6 15.4
VT Input Current [A]
1.1 1.4 1.9 2.8 3.9 5.0 6.7 8.5 16.0 22.5
VT Output Cur. Max. [A]
1.2 1.6 2.1 3.0 4.0 5.9 7.7 10.2 18.4 26.0
10 10 10 10 10 16 16 20 20 32
Recommended Fuse [A]
3NA3003 3NA3003 3NA3003 3NA3003 3NA3003 3NA3005 3NA3005 3NA3007 3NA3007 3NA3012
[mm
2
]
1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 2.5 4.0
Input Cable Min.
[awg]
17 17 17 17 17 17 17 17 13 11
[mm
2
]
2.5 2.5 2.5 2.5 2.5 6.0 6.0 6.0 10.0 10.0
Input Cable Max.
[awg]
131313131399977
[mm
2
]
1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 2.5 4.0
Output Cable Min.
[awg]
17 17 17 17 17 17 17 17 13 11
[mm
2
]
2.5 2.5 2.5 2.5 2.5 6.0 6.0 6.0 10.0 10.0
Output Cable Max.
[awg]
131313131399977
[kg]
1.3 1.3 1.3 1.3 1.3 3.3 3.3 3.3 5.5 5.5
Weight
[lbs]
2.9 2.9 2.9 2.9 2.9 7.3 7.3 7.3 12.1 12.1
w [mm]
73.0 73.0 73.0 73.0 73.0 149.0 149.0 149.0 185.0 185.0
h [mm]
173.0 173.0 173.0 173.0 173.0 202.0 202.0 202.0 245.0 245.0
d [mm]
149.0 149.0 149.0 149.0 149.0 172.0 172.0 172.0 195.0 195.0
w [inches]
2.87 2.87 2.87 2.87 2.87 5.87 5.87 5.87 7.28 7.28
h [inches]
6.81 6.81 6.81 6.81 6.81 7.95 7.95 7.95 9.65 9.65
Dimensions
d [inches]
5.87 5.87 5.87 5.87 5.87 6.77 6.77 6.77 7.68 7.68
http://nicontrols.com

Siemens MICROMASTER 440 Series Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Control Modes	Vector control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
