Siemens MICROMASTER 440 Series User Manual

International English 7 MICROMASTER 440 Specifications
MICROMASTER 440 Operating instructions
6SE6400-5CA00-0BP0
87
Input voltage range 3 AC 500 V – 600 V, ± 10 % (Unfiltered), Part 1
Order No. 6SE6440
-
2UE17-
5CA0
2UE21-
5CA0
2UE22-
2CA0
2UE24-
0CA0
2UE25-
5CA0
2UE27-
5CA0
2UE31-
1CA0
2UE31-
5DA0
2UE31-
8DA0
[kW]
0.75 1.5 2.2 4.0 5.5 7.5 11.0 15.0 18.5
Motor Output
Rating
[hp]
1.0 2.0 3.0 5.0 7.5 10.0 15.0 20.0 25.0
Output [kVA]
1.3 2.6 3.7 5.8 8.6 10.5 16.2 21.0 25.7
CT Output Cur. Max. [A]
1.4 2.7 3.9 6.1 9.0 11.0 17.0 22.0 27.0
CT Input Current [A]
2.0 3.2 4.4 6.9 9.4 12.3 18.1 24.2 29.5
VT Input Current [A]
3.2 4.4 6.9 9.4 12.6 18.1 24.9 29.8 35.1
VT Output Cur. Max. [A]
2.7 3.9 6.1 9.0 11.0 17.0 22.0 27.0 32.0
10 10 10 10 16 25 32 35 50Recommended
Fuse
[A]
3NA3803-6 3NA3803-6 3NA3803-6 3NA3803-6 3NA3805-6 3NA3810-6 3NA3812-6 3NA3814-6 3NA3820-6
[mm
2
]
1.0 1.0 1.0 1.0 1.5 2.5 4.0 6.0 6.0
Input Cable Min.
[awg]
17 17 17 17 15 13 11 9 9
[mm
2
]
10.0 10.0 10.0 10.0 10.0 10.0 10.0 35.0 35.0
Input Cable Max.
[awg]
777777722
[mm
2
]
1.0 1.0 1.0 1.0 1.0 2.5 4.0 4.0 6.0
Output Cable Min.
[awg]
17 17 17 17 17 13 11 11 9
[mm
2
]
10.0 10.0 10.0 10.0 10.0 10.0 10.0 35.0 35.0
Output Cable Max.
[awg]
777777722
[kg]
5.5 5.5 5.5 5.5 5.5 5.5 5.5 16.0 16.0
Weight
[lbs]
12.1 12.1 12.1 12.1 12.1 12.1 12.1 35.0 35.0
w [mm]
185.0 185.0 185.0 185.0 185.0 185.0 185.0 275.0 275.0
h [mm]
245.0 245.0 245.0 245.0 245.0 245.0 245.0 520.0 520.0
d [mm]
195.0 195.0 195.0 195.0 195.0 195.0 195.0 245.0 245.0
w [inches]
7.28 7.28 7.28 7.28 7.28 7.28 7.28 10.83 10.83
h [inches]
9.65 9.65 9.65 9.65 9.65 9.65 9.65 20.47 20.47
Dimensions
d [inches]
7.68 7.68 7.68 7.68 7.68 7.68 7.68 9.65 9.65
http://nicontrols.com

Siemens MICROMASTER 440 Series Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Control Modes	Vector control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
