7 MICROMASTER 440 Specifications International English
MICROMASTER 440 Operating instructions
88 6SE6400-5CA00-0BP0
Input voltage range 3 AC 500 V – 600 V, ± 10 % (Unfiltered), Part 2
Order No. 6SE6440- 2UE32-
2DA0
2UE33-
0EA0
2UE33-
7EA0
2UE34-
5FA0
2UE35-
5FA0
2UE37-
5FA0
[kW]
22.0 30.0 37.0 45.0 55.0 75.0
Motor Output Rating
[hp]
30.0 40.0 50.0 60.0 75.0 100.0
Output [kVA]
30.5 39.1 49.5 59.1 73.4 94.3
CT Output Cur. Max. [A]
32.0 41.0 52.0 62.0 77.0 99.0
CT Input Current [A]
34.7 47.2 57.3 69.0 82.9 113.4
VT Input Current [A]
47.5 57.9 69.4 83.6 113.4 137.6
VT Output Cur. Max. [A]
41.0 52.0 62.0 77.0 99.0 125.0
63 80 80 125 125 160
Recommended Fuse [A]
3NA3822-6 3NA3824-6 3NA3824-6 3NA3132-6 3NA3132-6 3NA3136-6
[mm
2
]
10.0 16.0 25.0 25.0 50.0 70.0
Input Cable Min.
[awg]
75330-2
[mm
2
]
35.0 35.0 35.0 150.0 150.0 150.0
Input Cable Max.
[awg]
2 2 2 -5 -5 -5
[mm
2
]
10.0 16.0 16.0 25.0 35.0 50.0
Output Cable Min.
[awg]
755320
[mm
2
]
35.0 35.0 35.0 150.0 150.0 150.0
Output Cable Max.
[awg]
2 2 2 -5 -5 -5
[kg]
16.0 20.0 20.0 56.0 56.0 56.0
Weight
[lbs]
35.0 44.0 44.0 123.0 123.0 123.0
w [mm]
275.0 275.0 275.0 350.0 350.0 350.0
h [mm]
520.0 650.0 650.0 850.0 850.0 850.0
d [mm]
245.0 245.0 245.0 320.0 320.0 320.0
w [inches]
10.83 10.83 10.83 13.78 13.78 13.78
h [inches]
20.47 25.59 25.59 33.46 33.46 33.46
Dimensions
d [inches]
9.65 9.65 9.65 12.6 12.6 12.6
http://nicontrols.com

Siemens MICROMASTER 440 Series Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Control Modes	Vector control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
