MOBILETT Plus HP SPR8-220.061.03 Page 6 of 22 Siemens AG
Rev. 03 09.03 CS PS 24 Medical Solutions
2 - 6 Display messages
Use 10 Generator ON.
The message
does not inter-
rupt a running
exposure.
The single tank tem-
perature measured
is > 50°C or
< 8°C.
• The generator is overheated and
must cool down or the generator
was stored in a cold room and must
warm up prior to use.
• Too high or too low ambient
temperature.
• As soon as the single tank
temperature is < 47°C, check the
measurement circuit for the
temperature (see page 140**),
contact K9.
CAL 12 During
preparation
Stored filament
value is lost.
• Check the voltage in the backup
battery (see page 110**). The
battery should have a voltage
> 2.8 V
• Check that the battery jumper is
securely attached (see page
110**).
• Make a new adaptation (see
section "P10 - Fast adaptation").
CAL 13 Generator ON The voltage supply
(60 V DC) to the fila-
ment circuit is
beyond its limit.
• Check fuse U6 on D8 (see page
160**).
• Check the filament supply voltage
+60 V DC (see page 160**).
Dis-
played
messages
Mode of
operation
Cause Possible reasons and advice
* See section "Monitoring the kV and mA values"
** Wiring diagram X037E
Tab. 1
