Siemens MOBILETT Plus HP Service Manual

MOBILETT Plus HP SPR8-220.061.03 Page 2 of 6 Siemens AG
Rev. 03 09.03 CS PS 24 Medical Solutions
1 - 2 General
Required documents 1
Required tools, measurement and auxiliary devices 1
• Standard service equipment*
• Digital multimeter
• Dose meter
• Storage oscilloscope with ± 2.5 % accuracy
• Torque wrench, 1 Nm - 3 Nm
• Spring scale
• Ceiling support *
• Lux meter
• Protective mat*
• Rope *
• Pulley block *
Lubricants 1
• All-purpose grease PD 2
• Viscogen oil
• Wiring diagram SPR8-220.051
• Functional description SPR8-220.041
All tools, measurement and auxiliary devices with the exception
of those marked " * " are listed along with their specifications in
the STC (Service Tools Catalog).
• Adjustment device for belt tension (Part No. 65 64 301)
• Current transformer (50 A : 50 mA)*
In addition, a metal film resistor with
10 Ohms; 0.5 W; 1 % is required*
Refer also to Speed Info 06/91
(Part No. 31 51 289)
• Calibration tool for DAP measuring system (Part No. 65 84 978)
