Siemens MOBILETT Plus HP Service Manual

MOBILETT Plus HP SPR8-220.061.03 Page 8 of 8 Siemens AG
Rev. 03 09.03 CS PS 24 Medical Solutions
7 - 8 Battery circuit and power conversion unit
• Remove the board including the aluminium plate.
• Replace the board.
Replacement of battery indicator D210 7
• Remove the right cover and the cover with the cassette compartment.
• Remove the two screws (pos. 1 / Fig. 15).
• Disconnect K203.
• Replace the battery indicator.
If the MOBILETT Plus HP is equipped with the DAP measuring
system (optional):
The power supply for the DAP measuring system must be discon-
nected during this procedure. Make sure to remember how the
cables were connected, and if needed use the "Installation
Instructions, DAP measuring system, SPR8-220.031.04..." for
additional help.
NOTICE
