Siemens MOBILETT Plus HP Service Manual

Replacement and repairs on the collimator 9 - 3
Siemens AG SPR8-220.061.03 Page 3 of 10 MOBILETT Plus HP
Medical Solutions Rev. 03 09.03 CS PS 24
Light field relative to the X-ray field 9
• Load a 35 x 35 cm (14" x 14") cassette with film.
• Place the cassette on a table or a similar surface.
• Set a SID of 100 cm (39"). Use a measuring tape.
• Switch on the collimator lamp and align the cassette. Collimate the light field to
25 x 25 cm (10" x 10").
• Mark the four corners with coins and mark one of the corners with two coins (Fig. 5).
• Set 52 kV, 2.0 mAs on the control panel.
• Release an exposure.
• Develop the film and measure the deviation between the light and the radiation field.
Acceptable deviation ± 1.7% of SID, (Fig. 6).
• If the deviation is more than 1.7%, adjust with the screws marked C and D (Fig. 2) to
move the light field closer to the radiation field.
• Repeat the test with a new exposure.
• If necessary, adjust again until the deviation between the light field and the radiation field
is within the tolerance specified.
• Reattach cover 1 (Fig. 1).
Equipment required: Cassette, X-ray film and coins
If the MOBILETT is equipped with a DAP measuring system,
remove the DAP ionization chamber first.
X-ray radiation!
If not observed, risk of radiation exposure.
Use radiation protection!
NOTE
CAUTION
