Step by step
Individual phone configuration
132
Network information
This overview in the user area of the Service menu pro-
vides you with information about the IP address of the
phone and the HTML address of the Web interface. It
also provides real-time data about the network activity
of the phone.
N Press the key shown.
Select and confirm the option shown.
if nec.j Enter and confirm the user password.
Select and confirm the option shown. You can browse
the following overview:
IP Address: Displays the IP address or name which was
assigned to the phone in the network.
WBM URL: HTTP address of the Web interface. This
address is specified in the address line of the Internet
browser and is used to call the Web interface of the
phone in the browser.
DNS domain: The DNS domain that can be assigned to
the telephone in addition to the IP address (e.g. http://
my-openStage.phone/).
LAN/PC-RX: The network or PC interface data packets
received are illustrated dynamically as columns.
LAN/PC-TX: The network or PC interface data packets
sent are illustrated dynamically as columns.
LAN/PC autonegotiated: [Yes|No]: Displays whether
the network or PC interface data transfer rate is set to
automatic (Ye s ) or manual (?No).
LAN/PC information: [10|100|1000] Mbit/s: Data
transfer rate of the network or PC interface. If an inter-
face is not in use, Link down is displayed.
User
Network information
