Introduction
19
Programmable Keys
optiPoint 410/420 economy/economy plus/standard S V6.0 is equipped
with 12 function keys all of which are user-programmable on two levels
(the "Stop/Escape" and "Shift" keys should be retained). Five of these keys
are pre-assigned in the first level
.
With the optiPoint 420 advance S V6.00 you also have the option of as-
sig-ning a name to the key which will then be displayed automatically.
Each feature key has a corresponding visual indicator (LED) to indicate the
status of the feature.
Function
Key
Function
1 Switch loudspeaker of the base unit on/off.
2 Redial one of the last 20 numbers dialed.
3 Displays the last 20 missed calls and permits selection,
editing and redial functions.
11 Cancel the current action.
12 Shift to the second key level.
Shift
6
7
8
9
10
12
1
3
4
5
2
11
Cancel/Rel.
Loudspeaker
Redial
Missed Calls
