8.1.3 Cable lengths X-300
Table 8- 9 Permitted cable lengths (copper)
Device:
SCALANCE
0 - 55 m
IE TP torsion cable with IE FC
RJ-45 Plug 180 or
0 - 45 m IE TP torsion cable with
IE outlet RJ-45 + 10 m TP cord
0 - 85 m
IE FC TP marine/trailing/ flexible
cable with IE FC RJ-45 Plug 180
or
0 - 75 m IE FC TP marine/
trailing/flexible cable + 10 m TP
cord over IE FC outlet RJ-45
0 - 100 m
IE FC TP standard cable with IE
FC RJ-45 plug 180 or
over IE FC outlet RJ-45 with 0 -
90 m IE FC TP standard cable +
10 m TP cord
X304-2FE ● ● ●
X306-1LD FE ● ● ●
X307-3 ● ● ●
X307-3LD ● ● ●
X308-2 ● ● ●
X308-2LD ● ● ●
X308-2LH ● ● ●
X308-2LH+ ● ● ●
X310 ● ● ●
X310FE ● ● ●
X320-1 FE ● ● ●
X320-3LD FE ● ● ●
Table 8- 10 Permitted cable lengths for Fast Ethernet fiber-optic cables
Device:
SCALANCE
Fiber FO cable lengths
X304-2FE 50/125 µm multimode
fiber
0-3 km
(1 dB/km at 1310 nm;
1200 MHz*km;
maximum insertion loss 0.5 dB;
9 dB max. permitted FO cable attenuation at 3 dB link power margin)
X306-1LD FE 9/125 µm single mode
fiber
0 -26 km
(0.5 dB/km at 1300 nm;
maximum insertion loss 0.5 dB;
14 dB max. permitted FO cable attenuation at 2 dB link power margin)
X310FE - -
X320-1 FE 50/125 µm multimode
fiber
0-3 km
(1 dB/km at 1310 nm;
1200 MHz*km;
maximum insertion loss 0.5 dB;
9 dB max. permitted FO cable attenuation at 3 dB link power margin)
50/125 µm multimode
fiber
0-3 km
(1 dB/km at 1310 nm;
1200 MHz*km;
maximum insertion loss 0.5 dB;
9 dB max. permitted FO cable attenuation at 3 dB link power margin)
X320-3LD FE
9/125 µm single mode
fiber
0 -26 km
(0.5 dB/km at 1300 nm;
maximum insertion loss 0.5 dB;
14 dB max. permitted FO cable attenuation at 2 dB link power margin)
