Description of the device
4.5 Components of the product
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
95
Order numbers
Type Power supply, position
of the terminals
Order number
1 x 24 V DC, PoE
cable outlet front
6GK5 324-4QG00-1HR2
1 x 100 V to 240 V AC,
PoE
cable outlet front
6GK5 324-4QG00-3HR2
1 x 24 V DC, PoE
cable outlet rear
6GK5 324-4QG00-1AR2
XR324-4M PoE
1 x 100 V to 240 V AC,
PoE
cable outlet rear
6GK5 324-4QG00-3AR2
4.5.8 Components shipped with the MM900 product
The following components are supplied with a SCALANCE MM900 media module:
● MM99x-2xx media module
● Operating Instructions (compact)
Note
Identification labels
The location labels identify the media modules and ship with the SCALANCE device.
4.5.9 Components shipped with the SFP product
Table 4- 3 Overview of the components shipped with the SFP product group
Plug-in terminal block
Device:
Transceiver
(Variant)
(signaling
contact)
2-pin
(24V)
4-pin
Device BAK Product CD
SFP991-1 (-) - - ● ● -
SFP991-1LD (-) - - ● ● -
SFP991-1LH+ (-) - - ● ● -
SFP992-1 (-) - - ● ● -
SFP992-1LD (-) - - ● ● -
SFP992-1LH (-) - - ● ● -
SFP992-LH+ (-) - - ● ● -
SFP992-1ELH (-) - - ● ● -
