Siemens SCALANCE X-300 Series Manual

Technical specifications
8.3 XR-300M technical specifications
SCALANCE X-300
164 Operating Instructions, 10/2010, A5E01113043-10
Table 8- 42 Electrical data: Transmitter output optical and receiver input
Transmitter output optical Receiver input Device:
SCALANCE
Variant
min.
[dBm]
max.
[dBm]
Sensitivity min.
[dBm]
max. input power
[dBm]
XR324-12M 2 x 24 V DC, cable outlet front
XR324-12M 1 x 100 to 240 V AC, cable outlet front
XR324-12M 2 x 24 V DC, cable outlet rear
XR324-12M 1 x 100 to 240 V AC, cable outlet rear
Note:
The values depend on the MM900 media modules and SFP transceivers
used.
8.3.3 XR-300M cable lengths
Table 8- 43 Permitted cable lengths (copper)
Device:
SCALANCE
Variant 0 - 55 m
IE TP torsion cable with
IE FC RJ-45 Plug 180
or
0 - 45 m IE TP torsion
cable with IE outlet RJ-
45 + 10 m TP cord
0 - 85 m
IE FC TP
marine/trailing/ flexible
cable with IE FC RJ-45
Plug 180 or
0 - 75 m IE FC TP
marine/ trailing/flexible
cable + 10 m TP cord
over IE FC outlet RJ-45
0 - 100 m
IE FC TP standard
cable with IE FC RJ-45
plug 180 or
over IE FC outlet RJ-45
with 0 - 90 m IE FC TP
standard cable + 10 m
TP cord
XR324-12M 2 x 24 V DC, cable outlet front
XR324-12M 1 x 100 to 240 V AC, cable outlet front
XR324-12M 2 x 24 V DC, cable outlet rear
XR324-12M 1 x 100 to 240 V AC, cable outlet rear
Note:
The values correspond to those of the permitted MM900 media modules
and SFP transceivers.
Table 8- 44 Permitted cable lengths (fiber-optic) Fast Ethernet
Device:
Media module
Variant Fiber FO cable lengths
XR324-12M 2 x 24 V DC, cable outlet front
XR324-12M 1 x 100 to 240 V AC, cable outlet front
XR324-12M 2 x 24 V DC, cable outlet rear
XR324-12M 1 x 100 to 240 V AC, cable outlet rear
Note:
The values correspond to those of the permitted MM900 media modules
and SFP transceivers.
Table 8- 45 Permitted cable lengths (fiber-optic) gigabit
Device:
Media module
Variant Fiber FO cable lengths
XR324-12M 2 x 24 V DC, cable outlet front
XR324-12M 1 x 100 to 240 V AC, cable outlet front
XR324-12M 2 x 24 V DC, cable outlet rear
XR324-12M 1 x 100 to 240 V AC, cable outlet rear
Note:
The values correspond to those of the permitted MM900 media modules
and SFP transceivers.
