Introduction
2.2 Product overview
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
23
NOTICE
Special feature of the optical ports
On the IE Switch X320-3LD FE, only the two ports of connectors 2 and 3 have the "long
distance" property:
 Connector 1: Multimode
 Connector 2: LD (long distance, single mode)
 Connector 3: LD (long distance, single mode)
2 optical interface transceivers possible (X320-3LD FE)
The device is also equipped with 2 optical interface transceivers.

1
(Fast Ethernet, long distance interface)

2
(Fast Ethernet, multimode interface)
Refer to "Transmitter output optical" and "Receiver input" in the technical specifications.
2.2.4 Product group X-300M
Product line Product
group
Device:
SCALANCE
(Variant) [Order number]
X-300 X-300M X308-2M (-) [6GK5 308-2GG00-2AA2]
Key to the naming of product group X-300M
Table 2- 5 Naming key: X308-2M
X 3 08 - 2 M
Product family
X = SCALANCE X
Product line
3 = 300
Number of
electrical ports
(8)
Hyphen Number of MM900 media
modules (2)
M = modular
(partially/fully
modular)
2.2.5 Product group XR-300M
Product line Product
group
Device:
SCALANCE
(Variant) [Order number]
XR324-12M (2 x 24 V DC, cable outlet front) [6GK5 324-0GG00-1AR2]
XR324-12M (1 x 100 to 240 V AC, cable
outlet front)
[6GK5 324-0GG00-3AR2]
XR324-12M (2 x 24 V DC, cable outlet rear) [6GK5 324-0GG00-1HR2]
X-300 XR-300M
XR324-12M (1 x 100 to 240 V AC, cable
outlet rear)
[6GK5 324-0GG00-3HR2]
