Introduction
2.2 Product overview
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
27
2.2.9 Product group XR-300M PoE
Interfaces
Type RJ-45 port electrical
10/100/1000 Mbps
Module slots
XR324-4M PoE 16 4
Components of the product
The following parts ship with a SCALANCE XR-324-4M PoE:
● Device with C-PLUG exchangeable medium
● 2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
mounting
● Connecting cable for the diagnostics port
● Operating Instructions (compact)
● Product CD with documentation and software
● With devices with power supply 100 to 240 V AC / 60 to 250 V DC:
– A 2-pin terminal block for the power supply
– A 2-pin terminal block for the signaling contact
● With devices with 24 V DC power supply:
– 4-pin terminal block for the power supply
– 2-pin terminal block for the signaling contact
– 4 adhesive feet for desktop mounting
Order numbers
Type Power supply, position
of the terminals
Order number
1 x 24 V DC, PoE
cable outlet front
6GK5 324-4QG00-1HR2
1 x 100 V to 240 V AC,
PoE
cable outlet front
6GK5 324-4QG00-3HR2
1 x 24 V DC, PoE
cable outlet rear
6GK5 324-4QG00-1AR2
XR324-4M PoE
1 x 100 V to 240 V AC,
PoE
cable outlet rear
6GK5 324-4QG00-3AR2
