8.5 XR-300M EEC technical specifications
SCALANCE X-300
174 Operating Instructions, 10/2010, A5E01113043-10
Table 8- 70 Permitted ambient conditions
Device:
SCALANCE
(Variant) Operating
temperature
Storage/transport
temperature
Relative humidity
at 25 °C during
operation,
maximum
Operating
altitude at max.
xx °C ambient
temperature
(1 x 24 V DC, cable outlet
front)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
(2 x 24 V DC, cable outlet
front)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
(1 x 100 to 240 V AC, cable
outlet front)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
(2 x 100 to 240 V AC, cable
outlet front)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
(1 x 24 V DC, cable outlet
rear)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
(2 x 24 V DC, cable outlet
rear)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
(1 x 100 to 240 V AC, cable
outlet rear)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
XR324-4M EEC
(2 x 100 to 240 V AC, cable
outlet rear)
-40 °C to 70 °C -40 °C to 70 °C < 95% no
condensation
2000 m at max.
55 °C, 3000 m at
max. 50 °C
8.5.2 XR-300M EEC connectors and electrical data
Table 8- 71 Interfaces
Type RJ-45 port electrical
10/100/1000 Mbps
Module slots
XR324-4M EEC 16 4
Table 8- 72 Connector for power supply and signaling contact
Plug-in terminal block for connecting: Device:
SCALANCE
Variant
Power supply
single
Power supply
redundant
Signaling contact
1 x 24 V DC, cable outlet front ● - 1 x 2-pin
2 x 24 V DC, cable outlet front - ● 2 x 2-pin
XR324-4M EEC
1 x 100 to 240 V AC, cable outlet front ● - 1 x 2-pin
