11.6 MM900 dimension drawings
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
267
11.6 MM900 dimension drawings
Note
The following dimension drawings are available for the MM900 product group.
Figure 11-22 MM900 dimension drawing 1: Electrical RJ-45 ports with securing collar
Figure 11-23 MM900 dimension drawing 2: Electrical RJ-45 ports without securing collar
