Description of the device
4.5 Components of the product
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
91
Note
Labels to identify the installed MM900 media modules are supplied with the modular devices
(M).
The following parts ship with a SCALANCE XR-300M:
● Device with C-PLUG exchangeable medium.
● 2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
mounting.
● A two-pin terminal block for the signaling contact.
● Connecting cable for the diagnostics port.
● Adhesive feet for desktop operation.
● Operating Instructions (compact)
● Product CD with documentation and software.
For devices with a 100 to 240 VAC power supply also:
● A two-pin connector for the power supply.
For devices with a 24 VDC power supply, also:
● A four-pin terminal block for the power supply.
4.5.4 X-300EEC product components
Apart from the device itself, the following components are also supplied with the switch:
Table 4- 2 Overview of the components shipped with the X-300EEC product group
Components of the product
Plug-in terminal block
Power
Device:
SCALANCE
(variants)
C-PLUG
Signaling
contact with
contact pins
24 V
...48 V
DC
100
...240 V AC
/ 60
...250 V DC
BAK
1
Product CD
X302-7EEC
1 x power supply unit 24 V DC,
printed board unvarnished
[6GK5302-7GD00-1EA3]
1 x power supply unit 24 V DC,
printed board varnished
[6GK5302-7GD00-1GA3]
● 1 x 2-pin 1 x 4-pin - ● ●
2 x power supply unit 24 V DC,
printed board unvarnished
[6GK5302-7GD00-2EA3]
2 x power supply unit 24 V DC,
printed board varnished
[6GK5302-7GD00-2GA3]
● 2 x 2-pin 2 x 4-pin - ● ●
