Siemens SCALANCE X-300 Series Manual

Technical specifications
8.4 Technical specifications for X-300EEC
SCALANCE X-300
168 Operating Instructions, 10/2010, A5E01113043-10
Table 8- 51 Installation options
Installation options Device:
SCALANCE
DIN rail S7-300 standard rail
1)
Wall
2)
19" rack
3)
X-300EEC
(all variants)
● ● ● ●
1)
Possible only with adapter (must be provided by installers).
2)
Wall mounting possible with suitable wall support.
3)
With mounting support
You will find the dimensions for the wall support in section Graphics (Page 251).
Table 8- 52 Permitted ambient conditions
Temperature range Device:
SCALANCE
Operation *
)
Storage / transportation
Relative humidity at 25°C
(operation)
Operating altitude
X-300EEC
(all variants)
-40°C through +70°C -40°C to +70°C ‹ 95 % (no condensation) 2000 m at max. 56°C
*
)
The IE Switch was type tested for 16 h at +85°C.
Table 8- 53 Mechanical stability
Device:
SCALANCE
Strain withstood /
category (standard)
Test conditions
X-300EEC
(all variants)
Vibration
(IEC 60068-2-6)
Frequency range 10 Hz to 150 Hz:
 Transit frequency: 58 Hz to 60 Hz
 Peak value of the displacement [mm] below the transit frequency: 0.075
 Peak value of the acceleration [g] above the transit frequency: 1
 Number of cycles per axis: 20
Frequency range 5 Hz to 150 Hz:
 Transit frequency: 8.4 Hz
 Peak value of the displacement [mm] below the transit frequency: 3.5
 Peak value of the acceleration [g] above the transit frequency: 1
 Number of cycles per axis: 10
 Octaves / min: 1
Frequency range 2 Hz to 100 Hz:
 Frequency range: 2 Hz to 100 Hz
 Transit frequency: 13.2 Hz
 Peak value of the displacement [mm] below the transit frequency:1
 Peak value of the acceleration [g] above the transit frequency: 0.7
 Number of cycles per axis: 10
 Octaves / min: 2
X-300EEC
(all variants)
Vibration
(IEEE1613 Class V.S.2)
 Velocity: <10 mm/s
 Frequency: 1...150 Hz
X-300EEC
(all variants)
Shock
(IEC 60068-2-27)
 Acceleration: 15 g
 Duration of the pulse: 11 ms
 Number of shocks per direction: 3
