Technical specifications
8.4 Technical specifications for X-300EEC
SCALANCE X-300
170 Operating Instructions, 10/2010, A5E01113043-10
Table 8- 57 Electrical data: Current consumption and power loss
Current consumption at... Power loss at ... Device:
SCALANCE
Device version (power supply)
24 to 48 VDC 100 to 240 VAC /
60 to 250 VDC
24 to 48 VDC 100 to 240 VAC /
60 to 250 VDC
24 to 48 VDC 0.8 to 0.4 A - 17 W - X302-7EEC
100 to 240 VAC /
60 to 250 VDC
- 0.4 to 0.3 A (AC)
0.3 to 0.1 A (DC)
- 18 to 19 W (AC)
17 to 18 W (DC)
24 to 48 VDC 0.5 to 0.3 A - 12 W - X307-2EEC
100 to 240 VAC /
60 to 250 VDC
- 0.3 to 0.2 A
0.3 to 0.1 A
- 12 to 13 W
12 to 13 W
Table 8- 58 Electrical data: Overcurrent protection
Device:
SCALANCE
Device version (power supply) Overcurrent protection of the power supply
Non-replaceable fuse
1 power supply unit 24 to 48 VDC T4A / 125 V (1 x) X302-7EEC / X307-2EEC
2 power supply units 24 to 48 VDC T4A / 125 V (2 x)
1 power supply unit 100 to 240 VAC / 60 to
250 VDC
T4A / 250V (1 x) X302-7EEC / X307-2EEC
2 power supply units 100 to 240 VAC / 60 to
250 VDC
T4A / 250V (2 x)
Table 8- 59 Electrical data of the signaling contact: Voltage, switching capacity
Device:
SCALANCE
Device version (power supply) Voltage at signaling contact Maximum switching capacity
(resistive load)
24 to 48 VDC 24 VDC 100 mA X302-7EEC /
X307-2EEC
100 to 240 VAC / 60 to 250 VDC
 240 VAC / 60 Hz
 24 VDC
 48 VDC
 240 VDC
 8 A
 8 A
 0.8 A
 0.1 A
Table 8- 60 Electrical data: Transmitter output (optical) and receiver input
Transmitter output (optical) *
)
Receiver input *
)
Device:
SCALANCE
Variant
Min. [dBm] Max. [dBm] Sensitivity min.
[dBm]
Max. input power
[dBm]
X302-7EEC / X307-2EEC all variants -19 -14 -32 -14
*
)
Values for glass fiber: 62.5 to 125 μm multimode
Table 8- 61 Overvoltage category
Device:
SCALANCE
General In the application range of EN 60255-27
X302-7EEC / X307-2EEC Overvoltage category II Overvoltage category III
