Description of the device
4.1 Compatibility of SCALANCE X-300
SCALANCE X-300
44 Operating Instructions, 10/2010, A5E01113043-10
● Network components in a ring structure with IE Switch X-300 as redundancy manager
– Electrical ring structure:
ESM/OSM
SCALANCE X-200
SCALANCE X-200IRT
SCALANCE XF200
SCALANCE XF204IRT
SCALANCE X-300 (it may be necessary to configure other ring ports)
SCALANCE X-400
– Optical ring structure:
SCALANCE X-400
SCALANCE X-300 (exceptions SCALANCE X310 and SCALANCE X310FE)
● Redundant coupling of networks
– In the network segment with the master-slave pair to be configured:
SCALANCE X-400
SCALANCE X-300
In the standby coupling also to SCALANCE X-200
– In the network segment to be coupled:
ESM/OSM
SCALANCE X-200
SCALANCE X-200IRT
SCALANCE XF200
SCALANCE XF204IRT
SCALANCE X-300
SCALANCE X-400
Note
All compatibility information assumes the correct use of the TP and FOC cables.
