8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
180 System Manual, 03/2011, A5E01051353-02
Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling Contained
in DS.Byte
Switch position at the digital input
module 2
115 DI2 — Format
(111)
8 — DS69.4
Switch position at the digital output
module 1
119 DO1 — Format
(119)
8 — DS69.5
Switch position at the digital output
module 2
124 DO2 — Format
(119)
8 — DS69.6
Shows the phase with maximum load 373 ETU ETU Format
(373)
3 — DS51.183
DS52.24*
Position and status of the circuit
breaker in the frame
24 COM15 COM20 Format (24) 4 — DS51.202
DS92.37
DS52.25*
Modules connected to the
CubicleBUS
88 COM15 — Format (88) 32 — DS92.20
DS91.48
Status of the inputs of the digital input
module 1
110 DI1 — Hex 8 — DS69.0
Status of the inputs of the digital input
module 2
114 DI2 — Hex 8 — DS69.1
Status of outputs of the digital output
module 1
118 DO1 — Hex 8 — DS68.14
Status of outputs of the digital output
module 2
123 DO2 — Hex 8 — DS68.15
Status of the connected PROFIBUS 17 COM15 COM20 Format (17) 3 — DS51.180
DS52.54*
Status of the circuit breaker
(on/off/powered, etc.)
328 BSS COM20 Format
(328)
8 — DS51.203
DS52.22*
DS92.40
Maintenance information about the
main contacts
405 ETU — Format
(405)
2 — DS91.40
* COM20 only
