Data library
8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
187
8.5.8 Data points for other measured values
The table below contains the data points for other measured values :
Table 8- 8 Data points for other measured values
Description Data
point
Source WL Source
VL
Format Length
(bits)
Scaling Contained in
DS.Byte
Mean value of the power factor 168 Meter. fct. — signed int 16 - 3 DS51.184
DS94.98
Power factor in phase L1 169 Meter. fct. — signed int 16 - 3 DS94.100
Power factor in phase L2 170 Meter. fct. — signed int 16 - 3 DS94.102
Power factor in phase L3 171 Meter. fct. — signed int 16 - 3 DS94.104
Minimum of the mean value of the power
factor
242 Meter. fct. — signed int 16 - 3 DS74.0
Maximum of the mean value of the
power factor
243 Meter. fct. — signed int 16 - 3 DS74.2
Temperature in the control cabinet (acc.
in COM15)
71 COM 15 — unsigned c
har
8 0 DS94.114
Minimum temperature in the control
cabinet
72 COM 15 — unsigned c
har
8 0 DS77.0
Maximum temperature in the control
cabinet
73 COM 15 — unsigned c
har
8 0 DS77.1
Temperature in circuit breaker (acc. in
BSS)
330 BSS — unsigned c
har
8 0 DS94.115
Minimum temperature in the circuit
breaker
74 COM 15 — unsigned c
har
8 0 DS77.2
Maximum temperature in the circuit
breaker
75 COM 15 — unsigned c
har
8 0 DS77.3
Active energy in normal direction [MWh] 238 Meter. fct. — unsigned
long
32 0 DS94.82
Active energy in normal direction [kWh] 433
1)
Meter. fct. — unsigned
long
32 0 DS94.116
Active energy in reverse direction [MWh] 239 Meter. fct. — unsigned
long
32 0 DS94.86
Active energy in reverse direction [kWh] 434
1)
Meter. fct. — unsigned
long
32 0 DS94.120
Reactive energy in normal direction
[MVarh]
240 Meter. fct. — unsigned
long
32 0 DS94.90
Reactive energy in normal direction
[kVarh]
435
1)
Meter. fct. — unsigned
long
32 0 DS94.124
Reactive energy in reverse direction
[MVarh]
241 Meter. fct. — unsigned
long
32 0 DS94.94
Reactive energy in reverse direction
[kVarh]
436
1)
Meter. fct. — unsigned
long
32 0 DS94.128
Frequency 3VL 396 — — unsigned
int
16 - 2 DS94.112
Frequency 262 Meter. fct. — unsigned
int
16 - 2 DS94.106
