Data library
8.5 Function classes
3WL/3VL circuit breakers with communication capability - PROFIBUS
198 System Manual, 03/2011, A5E01051353-02
8.5.13 Parameters of the SENTRON circuit breakers (communication, measured value
adjustment, etc.)
The table below contains the parameters of the SENTRON circuit breakers (communication,
measured value adjustment, etc.):
Table 8- 13 Parameters of the SENTRON circuit breakers (communication, measured value adjustment, etc.)
Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling Contained in
DS.Byte
PROFIBUS address 5 COM15 COM20 unsigned
int
8 0 DS160.5
Basic type of PROFIBUS data transfer 6 COM15 COM20 Hex 2 — DS160.6
Data in the cyclic profile of PROFIBUS 7 COM15 COM20 Format (7) 224 — DS160.8
IP address of the BDA PLUS 10 BDA PLU
S
— Format
(10)
40 — DS160.42
Assignment of the configurable digital
output module
129 conf. DO — Format
(129)
168 — DS128.46
Normal direction of incoming supply 145 Meter. fct. — Format
(145)
1 — DS128.20
Direction of rotation of phase 146 Meter. fct. — Format
(146)
1 — DS128.21
The voltage transformer can be star or
delta-connected on the primary side
162 Meter. fct. — Format
(162)
1 — DS128.4
Rated voltage of the system (on the
primary side)
164 Meter. fct. — unsigned
int
16 0 DS128.6
Secondary voltage of transformer 165 Meter. fct. — unsigned c
har
8 0 DS128.8
Length of period for calculating long-term
mean value
166 Meter. fct. — unsigned c
har
8 0 DS128.9
Number of sub-periods for calculating
long-term mean value
167 Meter. fct. — unsigned c
har
8 0 DS128.10
Lower limit of power transmission 372 ETU — unsigned
int
16 0 DS128.12
Ground fault transformer detection type 410 ETU ETU Format
(410)
2 — DS97.44
DS129.69
